Manhua MP18-20 Surge Protector Surge Protective Device Arrester Low Voltage House Surge Voltage Protection 20KA 320V

SURGE PROTECTIVE

Manhua MP18-20 Surge Protector Surge Protective Device Arrester Low Voltage House Surge Voltage Protection 20KA 320V Request quotation
Description
Report Item

Technical Data


Type: MP18-20

Max. continuous operating voltage Uc (V): 320

Nominal discharge current In 8/20 S (kA): 20

Max. load current Imax 8/20 S (kA): 40

Voltage protection level Up ( kV): 1.2

Functional indication: Green window: functional; red window: failed

Remote signal contacts: A couple of NO, NC contacts

Audio alarm: Optional

Wiring capacity: 1.5~35mm^2

House material: Complied with UL94V-0

House protection level: IP20

Installation method: 35mm DIN rail



About Feedback:

Dear friends: Welcome to my store, thank you! Your satisfaction is our aim, your feedback is very important for us sellers, if you are satisfied with the goods, please give us 5 star encourage if you are not 100% satisfied with the product, please be sure to contact me, please do not just hit bad review.I believe we can solve the problem together.

Quality assurance:

1.One year guarantee.
2.If the item is defective upon receipt, it should be within 7days from the date of receipt for exchange a new one (Buyer should return all original and undamaged items under re-saleable condition).

3.We supply free repairing service within one year of purchase. For the first 1 month, we will pay one way shipping cost(from us to your location);After 1 month of purchase, the buyer need to pay two ways of shipping cost.
4.One we get the returned items, we will send the replaced ones back as soon as possible.
5.Our warranty does not extend to any products that are physically damaged or under un-normal operating conditions as a result of misuse or improper installation on the parts.

Contact Me:

If you have any question, please contact us via Trademanager.
